Y Strainer Flange End

Other Valve

A flanged y strainer is a type of strainer used in pipelines to remove particles and debris from flowing liquid. It is designed with a y-shaped body and a mesh screen or perforated plate to trap solid particles while allowing the liquid to pass through. The flanged connections make it easy to install and remove the strainer from the pipeline for maintenance or cleaning. This type of strainer is commonly used in industrial applications such as water treatment, chemical processing, and oil and gas production.

Inquire Now

Share to:

Introduction

Ductile Iron Y Strainer Valve With Flange End

Size		L	D	D1	b	n	d	H	W.T(kg)
1.5	in	7.9	5	3.88	0.56	4	0.62	5.3	6.5
1.5	mm	200	127	98.6	14.2	4	16	135	6.5
2	in	8.9	6	4.75	0.62	4	0.75	5.9	9.6
2	mm	225.4	152	120.7	15.8	4	19	150	9.6
2.5	in	10.7	7	5.5	0.69	4	0.75	6.3	12.3
2.5	mm	273	178	139.7	17.5	4	19	160	12.3
3	in	11.5	7.5	6	0.75	4	0.75	7.9	16.9
3	mm	292	191	152.4	19	4	19	200	16.9
4	in	13.9	9	7.5	0.94	8	0.75	9.4	28.1
4	mm	352.4	229	190.5	23.9	8	19	240	28.1
5	in	16.4	10	8.5	0.94	8	0.88	11.4	40
5	mm	416	254	215.9	23.9	8	22	290	40
6	in	18.5	11	9.5	1	8	0.88	13	48.9
6	mm	470	279	241.3	25.4	8	22	330	48.9
8	in	21.4	13.5	11.75	1.12		0.88	15	82.3
8	mm	543	343	298.5	28.5		22	380	82.3
10	in	26	16	14.25	1.19	12	1	18.9	127.3
10	mm	660.4	406	362	30.2	12	25	480	127.3
12	in	30	19	17	1.25	12	1	21.7	200
12	mm	762	483	431.8	31.8	12	25	550	200
14	in	37.3	21	18.75	1.38	12	1.12	26.8	290
14	mm	946.3	533	476.3	35	12	29	680	290
16	in	42.5	23.5	21.25	1.44	16	1.12	30.7	385
16	mm	1079	597	539.8	36.6	16	29	780	385

Body	Ductile Iron
Cover	Ductile Iron
Mesh insert	Stainless steel PN-EN 10088-1:2014
Seal	Graphite CrNiSt
Screw	PN-EN ISO 4016:2011
Drain plug	Malleable Ductile Iron

Application:

Operating temp. up +120°C, 70°C for EPDM.

Cast iron flange strainer is for drinking and technological water systems.

It is recommended to install the strainer horizontally at the lowest point of the pipeline or at bending points.

In order to ensure full operational functionality, it is recommended to rinse the strainers with clean water periodically (twice per year) or more frequently, depending on the medium contamination level.
