Cast Iron Standard Test Weight

Custom Pipe Fittings

Rectangular Shape
Material: Cast Iron
Class: OIML M1
OEM and Custom Design Service Available

Inquire Now

Download

Share to:

Introduction

Iron cast weight refers to the given quality and specially shaped material measure. Generally used in weighing instrument verification. Weights must be combined with balance or weighing scales(weight used in the scale is often know as steelyard weights.), so that it can determine the quality of other objects.and is a kind of dependent material measure. Cast iron weights is made from grey cast iron or white iron by foundry technology. In order to avoid rusting, the surface of cast iron weights required to do proper disposal, like chrome plating, oiling, painting and bluing.

Description

Name	Cast Iron Standard Test Weight
Material	Cast Iron,Composite Iron And Steel for more than 500kgs
Process	Green sand & Resin sand & Precoated sand
Shape	Rectangular Shape
Standard	OIML/ASTM/NIST
Class	OIML M1/M2/M3
Nominal Value:	1kg/ 2kg / 5kg / 10kg / 20kg / 25kg / 50kg / 100kg / 200kg / 250kg / 500 kg, 1t / 2t / 5 ton
Density	7.2kg/dm3
Susceptibility	0.2
Surface treatment	Polishing/Sanding/Black Painting
MOQ	2 tons
HS CODE	84239000
Packing	Everything packing into small cardboard boxes, then, when all good <20kg, shipping pack with carton box, >20kg shipping with plywood pallet or wooden pallet
Application	industrial weights and laborator, chemical, medical calibration weights, Machine parts,commercial for all kinds of scales. OEM and Custom Design Service Availabl

Weight Sets

1mg-500mg	mg:1,2,2,5,10,20,20,50,100,200,200*,500
1mg-100g	mg:1,2,2,5,10,20,20,50,100,200,200*,500
	g:1,2,2,5,10,20,20,50,100
1mg-200g	mg:1,2,2,5,10,20,20,50,100,200,200*,500
	g:1,2,2,5,10,20,20,50,100,200,200*
1mg-500g	mg:1,2,2,5,10,20,20,50,100,200,200*,500
	g:1,2,2,5,10,20,20,50,100,200,200*,500
1mg-1kg	mg:1,2,2,5,10,20,20,50,100,200,200*,500
	g:1,2,2,5,10,20,20,50,100,200,200*,500,1000
1mg-2kg	mg:1,2,2,5,10,20,20,50,100,200,200*,500
	g:1,2,2,5,10,20,20,50,100,200,200,500,1000,2000,2000
1mg-5kg	mg:1,2,2,5,10,20,20,50,100,200,200*,500
	g:1,2,2,5,10,20,20,50,100,200,200,500,1000,2000,2000,5000
1mg-10kg	mg:1,2,2,5,10,20,20,50,100,200,200*,500
	g:1,2,2,5,10,20,20,50,100,200,200,500,1000,2000,2000,5000,10000
1mg-20kg	mg:1,2,2,5,10,20,20,50,100,200,200*,500
	g:1,2,2,5,10,20,20,50,100,200,200,500,1000,2000,2000,5000,10000,20000
