The Lifting bottom valve serves to restrict the water in the pipe from flowing back to the water source, generally it installed at the bottom of the pump's underwater suction pipe. There are many water inlet holes and reinforcement bars on the lifting bottom valve cover, which serve to block debris and are not easily blocked.
Lifting bottom valve
Size: DN40mm~300mm
Flange Ends: DIN PN16 or ANSI
Working Pressure: 0.6-1.6Mpa
Working Temperature:≤50℃
Media: Water
Body material:Cast Iron, Cast Steel or Stainless Steel.
Seal Ring: PTFE
D | DI | Z-0d | |
DN50 | 140 | 110 | 4-12 |
DN65 | 160 | 130 | 4-14 |
DN65 (10kg) | 160 | 145 | 4-14 |
DN80 | 185 | 150 | 4-18 |
DN80 (10kg) | 185 | 160 | 4-18 |
DN100 | 205 | 170 | 4-18 |
DN100 (lOKg) | 209 | 180 | 8-18 |
DN125 | 235 | 200 | 8-18 |
DN150 | 260 | 225 | 8-18 |
DN150(10kg) | 276 | 240 | 8-18 |
DN200 | 315 | 280 | 8-18 |
DN200(10kg) | 328 | 295 | 8-18 |
DN250 | 370 | 335 | 12-19 |
DN300 | 435 | 395 | 12-23 |
DN350 | 485 | 445 | 12-23 |
DN400 | 535 | 495 | 16-23 |
DN450 | 590 | 550 | 16-23 |
DN500 | 645 | 600 | 16-23 |
