Design standard: DIN3352

Flange: EN1092 PN10, P16, ANSI B.16.10, or JIS 10K

Working pressure: PN10/PN16/PN25, 125LB, 150LB, 10K

Face-to-face dimensions: DIN3202 F1

Test standard: din3230

Working temperature: 0 to 80ºC

Body materials: ductile iron(GGG50)

Screen: SS304

Plug: carbon steel

Gasket: EPDM/NBR

Coating: blue epoxy powder

Size: DN50-DN700
